Productdetails:
|
IP Tarief: | IP68/IP69K | Comité Grootte: | 15.6“ Geleid |
---|---|---|---|
Resolutie: | 1920 x 1080 | Bewerker: | De Vierlingkern J1900 2.0GHz van Intel Celeron |
Geheugen: | DDR3L 1333MHz 4GB, tot 8GB | HDD: | 32G SSD/(64G/128G/250G/500G SSD) Facultatief |
I/O Interface: | VGA/HD-MI/LAN/USB/COM | Touchscreen: | Weerstand biedende Aanraking/Capacitieve Aanraking |
Machtsinput: | Gelijkstroom 12V~24V/Facultatieve gelijkstroom 9V~36V | Besturingssysteem: | Win7/8/10/Linux/Ubuntu |
Hoog licht: | linux Waterdichte Touch screenpc,fanless Waterdichte Touch screenpc,leesbare fanless industriële paneelpc |
Eigenschap
Waterdichte PC is ideaal voor toepassingen zoals mariene/Varende boot, medische apparatuur, vochtig productiemateriaal, de voedselindustrie, chemische productie en andere openluchttoepassingen.
1.15.6“ TFT-leiden, resolutie 1920*1080, weerstand biedende aanraking
Wpc-J156WBR | ||
Systeem | Cpu | De Vierlingkern J1900 2.0GHz van Intel Celeron |
L2 Geheim voorgeheugen | 2MB | |
Chipsets | Intel Bay Trail-Soc | |
Geheugen | DDR3L 1333MHz 4GB, tot 8GB | |
Harde schijf | 1 x mSATA 32G SSD/(64G/128G/250G/500G SSD) Facultatief | |
Grafiek | Intel HD Graphics | |
Netwerk | De haven van Intel 82583V 1000 Mbps | |
Audio | Het Audiocontrolemechanisme van Realtek ACL662 | |
Verrichtingssysteem | Windows7/8/10, Linux, Unix, QNX | |
I / O | VGA | 1 x VGA/1 (Facultatief) x hd-MI |
LAN | 1 x-(Facultatief) LAN | |
USB | (Facultatieve) 3 x x USB2.0/1 USB3.0 | |
Com | (Facultatieve) 2 x RS232 | |
Draadloos Netwerk | (Facultatief) WiFi + Bluetooth | |
Andere I/O Interface | 1 x-Machtsschakelaar | |
LCD Comité | Comité Grootte | 15.6“ Geleid |
Resolutie | 1920 x 1080 | |
Beeldverhouding | 16:9 | |
Vertoningshelderheid | 600 cd/m2 | |
Contrastverhouding | 800:1 | |
Kleuren | 16.7M, 76% NTSC | |
Reactietijd | 30 (Type.) (Tr/Td) Mej. | |
Het bekijken Hoek | 80 / 80/80/65 (CR≥10) (L/R/U/D) | |
Touch screen | Touch screentype | 5 draad weerstand biedende aanraking |
Overbrenging | >85% | |
Reactietijd | <5ms> | |
Oppervlaktehardheid | ≥3H | |
Leveringsvoltage | 5.0V gelijkstroom | |
Het aanrakingsleven | ≧ 1000W | |
Institutioneel | Materiaal | Aluminiumlegering Shell |
Kleur | (Facultatief) zilver/Zwarte | |
VESA Mounting | VESA: 100 x 100 mm | |
Waterdicht Tarief | IP67/IP68/IP69K | |
Productdimensie | 398 x 247 x 52 mm | |
Verwijderde Grootte | / | |
Verpakkingsgrootte | 460 x 180 X400 mm | |
Brutogewicht | 7,0 kg | |
Macht en Milieu | Werkende Temperatuur | -10~60°C |
Opslagtemperatuur | -20~80°C (- 22~176°F) | |
Relatieve Vochtigheid | non-condensing 5%~95%@40°C, | |
Trillingswaaier | 5-500 Herz, 0,026 G2/Hz, 2,16 Grms, X, Y, Z, 1 uur per as | |
Externe Voeding | AC 100 - 240V~50/60Hz, 1.5A | |
Het werk Voltage | Gelijkstroom 12V~24V/facultatief (+9V~36V) | |
Machtsconsumptie | ≦30W |
Verpakkingslijst
Wpc-J156WBR maak Comité PC waterdicht
Waterdichte VGA/RS232/LAN/USB/COM-kabels
1x nutsdvd Bestuurder
1x machtsadapter
Toepassingen
Industriële automatisering
Mens/machine-interface
Marien controlesysteem
de lassenindustrie
toeziende controle
numerieke controleapparaat
FAQ
1. Q: Bent u een fabrikant of een handelsmaatschappij?
A: Wij zijn een professionele fabrikant met meer dan 10 jaar ervarings op industrieel automatiseringsgebied.
2. Q: Verleent u ODM/OEM of de aangepaste dienst?
A: Ja, steunen wij OEM&ODM-de dienst, laten u de producten krijgen u precies wilt.
3. Q: Welke certificatie hebt u?
A: Er zijn de certificaten van Ce, van RoHS, FCC, van IP68, IP69K-, enz.
4. Q: Hoe lang is de garantie?
A: Onze fabriek beloofde garantie is 1 jaar.
5. Q: Wat is de levertijd?
A: 3 werkdagen voor steekproevenorde, 15 werkdagen voor massaproduktie.
6. Q: Wat is MOQ?
A: Steekproef testen is aanvaardbaar, is de prijs overeen te komen voor bulkorder.
